Applications such as artificial intelligence, modeling and simulation, and graphic rendering
| Excellent performance and high cost-effectiveness | Supports 2 AMD EPYCs ™ 7002/7003 series processors, with a maximum of 64 cores and 128 threads per CPU, supporting a maximum of 280W TDP CPU Supports 16 DDR4 memory, with a maximum frequency of 3200MHz, providing excellent memory bandwidth and capacity. |
Flexible configuration and strong scalability | Supports 6 standard PCIe 4.0 expansion slots Supports 12 onboard SATA 3.0 Supports up to 4 U2 NVMe to meet mainstream application requirements |
Stable, reliable, and intelligent management | Integrated intelligent management chip, providing an open management platform, supporting multiple management protocols such as IPMI2.0 Support various management functions such as remote KVM, virtual media, critical component status monitoring, and abnormal alarms |
| Function | A3DRL-N Technical Specifications |
| form | E-ATX |
| processor | Supports 2 AMD EPYCs ™ 7002/7003 series processors, up to 64 cores per chip, with a maximum power of 280W 4 xGMI links |
| Memory | Supports 16 DDR4 memory slots, up to 3200MHz, supports RDIMM/LRDIMM |
| Memory Controller | Integrated 6Gb/s SATA controller; Supports external 12Gb/s SAS HBA and 12Gb/s SAS RAID controller |
| Onboard storage interface | Supports 12 onboard SATA 3.0, 2 SFF-8643+4 7pin SATA Supports 1 M.2 (PCIe 4.0 x42280&22110) |
| PCIe extension | Supports 6 PCIe expansion slots (3 PCIe 4.0 x16+3 PCIe 4.0 x8) |
| network | 1 1Gb RJ45 dedicated management network port Two 1Gb RJ45 data network ports, supporting NCSI |
| port | Front end: 1 VGA, 2 USB 3.0 Rear: 1 VGA, 4 USB 3.0, 1 RJ45 management network port, 1 COM port, 2 1Gb RJ45 data network ports |
| manage | Integrated ASPEED AST2500 BMC management chip, supporting IPMI2.0, KVM, virtual media and other functions |
| Physical dimensions | 12"×13"（307.4mm*331.5mm） |
| Operating system support | Supports Microsoft Windows Server, Microsoft Hyper-V Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, Oracle Linux, VMware ESXi, Citrix XenServer |
