High performance computing, VDI, AI deep learning training, media video streaming, cloud gaming, animation and modeling, design and visualization, 3D rendering, diagnostic imaging
| Excellent performance and high cost-effectiveness | Supports 2 x 4th Gen Intel® Xeon® Scalable processors with a maximum TDP of 350W and strong computing performance; Supports 4 x double-width, FHFL GPUs, with a maximum power consumption of 450W and strong heterogeneous computing performance; Supports 16 x DDR5 DIMMs, with a maximum frequency of 4800MHz, and a 50% increase in memory bandwidth compared to the previous generation; |
Flexible configuration and strong scalability | Supports two forms: rack and tower, meeting the needs of various scenarios in data centers and workstations; Flexible local storage, supporting 12 x 3.5-inch hard drives, optional SAS/SATA/NVMe; Excellent scalability, supporting 7 x standard PCIe 5.0x16 expansion slots; |
Stable, reliable, and intelligent management | The key components of the system are designed with redundancy and hot swapping, while supporting tool free disassembly and assembly to improve fault maintenance efficiency and system availability; Integrated intelligent management chip, providing an open management platform, supporting multiple management protocols such as IPMI2.0, Redfish, SNMP, etc; Supporting various management functions such as remote KVM, virtual media, critical component status monitoring, and abnormal alarms, achieving comprehensive remote system level intelligent management; |
| Function | 5024G-NR3 Technical Specifications |
| Form | 4U tower type, supporting two forms: rack type and tower type |
| Processor | Supports 2 x 4th Gen Intel® Xeon® Scalable processors, supporting up to 350W |
| Chipset | Intel C741 |
| Memory | 16 x DDR5 memory slots, 1DPC, up to 4800MHz Supports for RDIMM, 3DS RDIMM, and up to 4TB of memory |
| Storage Controller | Integrated 6Gb/s SATA controller, optional support for 12Gb/s SAS HBA and 12Gb/s SAS RAID card |
| Storage | Supports 12 x 3.5-inch hard drives with optional SAS/SATA/NVMe Supports 2 x M.2 (2280/22110, PCIe 4.0x4) |
| PCIe extension | 7 x standard PCIe 5.0 expansion slots |
| GPU | Up to 4 x double-width, FHFL GPUs can be supported |
| Network | 1 x 1Gb RJ45 dedicated management network port 2 x 1Gb RJ45 data network ports and LAN1 supports NCSI |
| Manage | Integrated BMC management chip AST2600, supporting functions such as IPMI2.0, Redfish, SOL, KVM, virtual media, etc |
| Safety | Supports TPM security module, intrusion detection when opening the chassis cover, and lock the upper cover of the chassis |
| Fan | Standard with 4 x system fans (8038,14000 RPM) Optional 4 x rear fans (8038,14000 RPM) |
| Power supply | Can be configured with 2 x power modules, supports 1+1 redundancy, and supports hot swapping |
| I/O interface | Front end: 1 x VGA, 2 x USB 3.0 |
| CD drive | Optional supports for built-in optical drive |
| Grounding | Rack style support for tool free installation of rails |
| Security panel | Supports for optional safety panels |
| Size | 437x175x683mm (rack mounted form) |
| Temperature | Working temperature: 5 º C -35 º C (without direct sunlight) Storage temperature: -40 º C -65 º C |
| Operating system support | Microsoft Windows Server、Red Hat Enterprise Linux、SUSE Linux Enterprise Server、CentOS、Ubuntu、Oracle Linux； |
