Virtualization, enterprise servers, applications and data services, computationally intensive applications, cloud computing
| Ultimate performance meets critical application requirements | Support for fourth generation Intel ® xeon ® scalable processor adopts a new Microarchitecture core, supports the highest 350W model, and has strong computing performance; It supports 32 DDR5 memories with a maximum frequency of 4800 MHz, and the Memory bandwidth is 50% higher than that of the previous generation; Supporting PCIe 5.0, doubling the bandwidth, greatly improving the system's scalability. |
| Flexible configuration and on-demand selection | Hardware module decoupling design enables flexible configuration of computing, storage, and network to meet different business needs; Support flexible selection of 3.5 "or 2.5" hard disk modules, with a maximum support of 24 U.2 NVMe; Supports up to 10 standard PCIe expansion slots, with optional PCIe 5.0 or PCIe 4.0; Supports OCP NIC 3.0 network expansion, optional extension 4 × 1GbE/2 × 10Gb SFP+/4 × 10Gb SFP+/2 × 25Gb SFP28 network configuration. |
| Stable, reliable, and intelligent management | The key components of the system are designed with redundancy and hot swapping, while supporting tool free disassembly and assembly to improve fault maintenance efficiency and system availability; Integrated intelligent management chip, providing an open management platform, supporting multiple management protocols such as IPMI2.0, Redfish, SNMP, etc; Supporting various management functions such as remote KVM, virtual media, critical component status monitoring, and abnormal alarms, achieving comprehensive remote system level intelligent management. |
| Functional | 2024G-NR3 Technical Specifications |
| Form | 2U rack server |
| Processor | 1/2 4th generation Intel ® xeon ® scalable processor, supporting up to 350W |
| Chipset | Intel C741 |
| Memory | 32 DDR5 memory slots, 16 channels in total, up to 4800MHz Supports RDIMM, 3DS RDIMM, and up to 8TB of memory |
| Storage controller | Integrated 6Gb/s SATA controller for storage controller; Optional support for 12Gb/s SAS HBA and 12Gb/s SAS RAID controller |
| Storage | Front end:Support up to 12 3.5-inch or 25 2.5-inch hard drives After:Support up to 4 3.5-inch+2 2.5-inch hard drives or 2 3.5-inch+4 2.5-inch hard drives Built in:Support 2 M.2 (2280/22110, PCIe 4.0 x4) Supports up to 24 U2 NVMe SSDs |
| PCI-E extension | Supports up to 10 standard expansion slots |
| GPU | Supports up to 3 dual width GPUs or 6 single width GPUs |
| Network | 1 1GbE RJ45 for IPMI1 1Gb RJ45 dedicated management network port 1 OCP NIC3.0 standard slot, optional 4 × 1GbE/2 × 10Gb SFP+/4 × 10Gb SFP+/2 × 25Gb SFP28 OCP network card |
| Administration | Integrated BMC management chip, supporting functions such as IPMI2.0, Redfish, SOL, KVM, virtual media, etc Provide 1 1Gbps RJ45 dedicated management port with optional LCD management module |
| Security | Optional TPM/TCM security module, intrusion detection when opening the chassis cover, and locking the upper cover of the chassis |
| Power | Capable of configuring 2 power modules, supporting 1+1 redundancy and hot swapping |
| Port | Front end: 1 VGA, 2 USB 3.0, 1 LCD Mini USB Post: 1 VGA, 2 USB 3.0, 1 RJ45 management network port, 1 COM |
| Size | Rack mounted 2U, width 448mm x height 87mm x depth 763mm (including hanging ears 783mm) |
| Temperature | Working temperature: 5 º C -35 º C (without direct sunlight) Storage temperature: -40 º C -65 º C |
| Operating system support | Microsoft Windows Server, Microsoft Hyper-V Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, Oracle Linux, VMware ESXi, Citrix XenServer |
