Virtualization, cloud computing, high-end enterprise servers
Ultra-high Performance and Superior Storage Capacity | Powered by Intel® Xeon® Scalable Processors, support up to 24 DDR4 DIMMs with maximum 9.0TB memory capacity/support 4 x 3.5-inch or 10 x 2.5-inch hot-swappable SAS/SATA hard drives or 10 x 2.5-inch NVMe hard drives 205W CPU low-latency NVMe driver and high power GPU will bring more improvement in performance |
Energy Saving and Easy Maintenance | Support Intel® Node Manager to achieve power cap control to save energy. Support High Voltage Direct Current (HVDC) technology In contrast with common power supply/HVDC has lower electrical losses and higher power conversion efficiency in energy saving In order to save investment in electricity and improve energy efficiency provides diverse PSUs like 550W 800W 1300W 1600W for option And 1022G-NR2 supports diverse power input as 110 VAC 220 VAC 240V VDC 336 VDC-48 VDC On-Board iBMC management module supports many management features like IPMI SOL KVM Over IP virtual media etc It improves the computing density and lowers overall expenditure through internal space optimization even in 1U chassis |
Ultra-high Density and Flexible Scalability | 1022G-NR2 is an ideal 1U server combining all superior performance, excellent scalability and high density in one. Maximum TDP205W CPU and full NVMe configuration are applicable to provide extremely high computing performance in limited space. With up to 5 PCIe slots and 2 standard PCIe slots among, plus applications acceleration to multiple IO it provides the excellent scalability Outstanding cooling design and premium components ensure stable running under environment of 5℃~ 35℃ |
| Function | 1022G-NR2 Technical Specifications |
| Form | 1U rack server |
| processor | Single or Dual 1st Gen Intel® Xeon® Scalable Processors 3100 4100 5100 6100 8100 series |
| chipset | Intel ® C621 |
| Memory | 24 DDR4 DIMM slots, 12 memory channels ( Specific CPU and Intel® Optane DCPMM will be required ) |
| storage | On-Board 6Gb/s SATA controller Up to 4 hot-swap 3.5''/2.5'' SAS/SATA hard drives Or up to10 hot-swap 2.5'' SAS/SATA/NVMe hard drives Support 1 PCIe M.2 (80/110mm) |
| PCI-E extension | Up to 4 PCIExpress3.0 expansion slots (including 2 dedicated slots) |
| GPU | Two half length single width GPUs |
| Network | 2 On-Board 1GbE RJ45 ports 1 RJ45 dedicated Ethernet management port Optional 2x1GbE 4x1GbE 2x10GbE 4x10GbE 2x25GbE 2x40GbE NIC mezzanine card Support various standard PCIe NIC |
| manage | On-Board BMC chip, support remote management, such as IPMI2.0, KVM Over IP, SOL, SNMP etc |
| safety | Optional TPM security module |
| power supply | Optional 110 VAC 220 VAC 240 VDC 336 VDC-48 VDC |
| port | 4 USB3.0 ports (2 rear, 2 front) |
| System Fan | 7 4056 system fans/ N+1 redundant fans/ supported by plug and play |
| size | Rack mounted 1U/ width 436mm x height 43.6mm x depth 808mm (excluding hanging ears 788mm) |
| temperature | Standard operating temperature: 5℃~35℃ (41°F ~ 95°F) "no direct sustained sunlight |
| Supported operating systems | Microsoft Windows Server Microsoft Hyper-V server Red Hat Enterprise Linux SUSE Linux Enterprise Server CentOS Ubuntu Fedora Solaris Oracle Linux FreeBSD VMware ESXi Citrix XenServer |
